Wago 221 Wire Connector
Wago 221 Wire Connector

Wago 221 Wire Connector

Sale price$3.00

Protect Your Solar Aeration System

The WAGO 221 Wire Connector provides a clean, reliable, and serviceable method of protecting your Durvela Solar Aeration Fan Kit from electrical faults. Installed inline with the 12V DC power supply, the connector securely houses a replaceable blade fuse while maintaining the trusted performance and ease of use of the WAGO 221 connector system.

In the event of a short circuit or wiring fault, the fuse interrupts the electrical supply before damage can occur to the fan, solar panel, thermostat, or wiring. The transparent housing allows for quick visual inspection, while the tool-free lever connectors make installation and future servicing fast and simple.

Features

  • Protects the 12V DC power circuit with a replaceable inline fuse
  • Compatible with the Durvela Solar Aeration Fan Kit
  • Reliable WAGO 221 lever-lock connection technology
  • Quick, tool-free installation and maintenance
  • Transparent housing for easy inspection
  • Compact design fits neatly inside the weather-resistant enclosure
  • Reusable connector simplifies servicing and component replacement
  • Designed for low-voltage DC applications

Typical Application

The WAGO 221 Fuse Connector is installed inline on the positive (+) 12V DC supply between the electrical components, protecting the 12V waterproof aeration fan, capillary thermostat, and associated wiring from overcurrent conditions.

Why Use an Inline Fuse?

A properly sized fuse is one of the simplest and most effective ways to protect electrical equipment. If wiring becomes damaged or a component develops a fault, the fuse opens the circuit before excessive current can overheat wiring or damage connected components, helping improve system safety and reliability.

For best performance, pair this connector with the Durvela Solar Aeration Fan Kit, Capillary Thermostat, and Stainless Steel Thermowell to create a dependable, temperature-controlled compost aeration system.

Item Number:
Wago 221 Wire Connector
Wago 221 Wire Connector Sale price$3.00

Product details and compatibility

Technical highlights

• Tool-free lever connection for fast installation and maintenance

• Reusable design allows wires to be disconnected and reconnected without damaging the connector

• Accepts both solid and stranded copper conductors

• Transparent housing provides visual confirmation of proper wire insertion

• Compact size fits easily inside Durvela electrical enclosures

• Genuine WAGO CAGE CLAMP® spring connection for reliable, vibration-resistant electrical connections

Technical specifications

Manufacturer: WAGO

Model: 221-412

Connector type: Lever-operated splicing connector

Number of conductors: 2

Connection technology: CAGE CLAMP® spring connection

Compatible conductor material: Copper

Wire size: 24–12 AWG (0.14–4.0 mm²)

Rated current (IEC): 32 A

Rated voltage (IEC): 450 VAC

Strip length: 11 mm (0.43 in)

Housing: Transparent polycarbonate with orange operating levers

Operating temperature: Up to 85°C (185°F)

Reusable: Yes

Installation and use
  1. Disconnect all power before making or modifying electrical connections.
  2. Strip approximately 11 mm (7/16 in) of insulation from each copper conductor.
  3. Lift the orange lever completely.
  4. Insert the stripped conductor until it bottoms out inside the connector.
  5. Close the lever firmly to clamp the conductor.
  6. Gently pull on each wire to verify it is securely retained.
  7. Confirm the conductor is fully inserted by viewing it through the transparent housing.
  8. Install the completed connection inside a suitable weather-resistant enclosure when used outdoors.
Downloads and documentation

• WAGO 221 Series Product Data Sheet

• Durvela Solar Aeration Kit Installation Guide

• Durvela Solar Aeration Kit Wiring Diagram

• Durvela Replacement Parts Guide

Important notes

• Use only copper conductors within the specified wire size range.

• Always disconnect power before installing or servicing electrical connections.

• Do not exceed the connector's published electrical ratings.

• Inspect each connection to ensure the conductor is fully inserted before closing the enclosure.

• For outdoor applications, install the connector inside a weather-resistant enclosure to protect it from moisture and contamination.

• This connector is intended for low-voltage Durvela system wiring and replacement-part applications.

Durvela product support Contact Durvela for help confirming compatibility, selecting a replacement part, or installing this product.
